Aries Electronics, Inc.
| Part Number | 1109523 | Manufacturer | Aries Electronics, Inc. |
|---|---|---|---|
| Description | SOCKET ADAPTER DIP TO TO-8 | Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Quantity Available | 9233 pcs | Data sheet | 1109523.pdf |
| Termination Post Length | 0.125" (3.18mm) | Termination | Solder |
| Series | Correct-A-Chip® 1109523 | Pitch - Post | - |
| Pitch - Mating | 0.100" (2.54mm) | Other Names | A330 |
| Operating Temperature | - | Number of Pins | 8 |
| Mounting Type | Through Hole | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Material Flammability Rating | UL94 V-0 | Manufacturer Standard Lead Time | 6 Weeks |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | Housing Material | Polyamide (PA46), Nylon 4/6, Glass Filled |
| Features | Socket Included | Detailed Description | IC Socket Adapter DIP, 0.3" (7.62mm) Row Spacing To JEDEC Through Hole |
| Current Rating | 1A | Convert To (Adapter End) | JEDEC |
| Convert From (Adapter End) | DIP, 0.3" (7.62mm) Row Spacing | Contact Material - Post | Brass |
| Contact Material - Mating | Beryllium Copper | Contact Finish Thickness - Post | 200.0µin (5.08µm) |
| Contact Finish Thickness - Mating | 10.0µin (0.25µm) | Contact Finish - Post | Tin-Lead |
| Contact Finish - Mating | Gold | Board Material | FR4 Epoxy Glass |
