TE Connectivity AMP Connectors
| Part Number | 3-825437-1 | Manufacturer | TE Connectivity AMP Connectors |
|---|---|---|---|
| Description | MOD 2 PINHDR 1X31P. | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 32746 pcs | Data sheet | 3-825437-1.pdf |
| Voltage - DC Spark Over (Nom) | Brass | Type Attributes | - |
| Termination | Solder | Style | Board to Board or Cable |
| Stacking Direction | Male Pin | Shrouding | 0.100" (2.54mm) |
| Shield Termination | Square | Series | AMPMODU Mod II |
| Row Spacing - Mating | Unshrouded | RoHS Status | Bulk |
| Ripple Current - Low Frequency | - | Pitch - Connector | - |
| Overall Contact Length | 0.126" (3.20mm) | Operating Temperature | -65°C ~ 105°C |
| Number of Rows | 1 | Number of Positions | 31 |
| Number of Contacts | 98.4µin (2.5µm) | Mounting Type | Through Hole, Right Angle |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material Flammability Rating | UL94 V-0 |
| Material - Insulation | All | Manufacturer Part Number | 3-825437-1 |
| Length - Post (Mating) | - | Insulation Material | Tin |
| Insulation Height | - | Features | - |
| Expanded Description | 31 Positions Header, Breakaway Connector Through Hole, Right Angle | Description | MOD 2 PINHDR 1X31P. |
| Current Rating | 5A | Current - Max/Contact | Push-Pull |
| Contact Length - Post | 0.264" (6.70mm) | Contact Length - Mating | - |
| Contact Finish Thickness - Post | Polybutylene Terephthalate (PBT) | Contact Finish Thickness - Mating | Gold |
| Contact Finish - Post | 3.9µin (0.10µm) | Contact Finish - Mating | 0.100" (2.54mm) |
| Connector Type | Header, Breakaway | Actual Diameter | Green |
