RT315024

Agastat Relays / TE Connectivity

Image may be representation. See specifications for product details.

Product Overview

Part Number:	RT315024
Manufacturer/Brand:	Agastat Relays / TE Connectivity
Product description	RELAY GEN PURPOSE SPDT 16A 24V
Datasheets:	RT315024.pdf
RoHs Status	Lead free / RoHS Compliant
Stock Condition	12943 pcs stock
Ship From	Hong Kong
Shipment Way	DHL/Fedex/TNT/UPS/EMS

Download Product Details PDF

In Stock 12943 pcs

Reference Price (In US Dollars)

1 pcs: $2.615

20 pcs: $2.451

40 pcs: $2.179

60 pcs: $2.07

100 pcs: $1.961

260 pcs: $1.811

Request Quote: Please complete all required fields with your contact information.Click "SUBMIT RFQ" we will contact you shortly by email. Or Email us:[email protected]

Target Price:
Qty:

Total:$2.615

Please give us your target price if quantities greater than those displayed.

Part Number
Company Name
Contact Name
E-mail
Message

Specifications of RT315024

Part Number	RT315024	Manufacturer	Agastat Relays / TE Connectivity
Description	RELAY GEN PURPOSE SPDT 16A 24V	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	12943 pcs	Data sheet	RT315024.pdf
Turn On Voltage (Max)	16.8 VDC	Turn Off Voltage (Min)	2.4 VDC
Termination Style	PC Pin	Switching Voltage	400VAC - Max
Series	RT1, SCHRACK	Release Time	6ms
Relay Type	General Purpose	Packaging	Tube
Other Names	1-1393240-4 1-1393240-4-ND 113932404 PB1697 RT315024-ND	Operating Temperature	-40°C ~ 85°C
Operate Time	8ms	Mounting Type	Through Hole
Moisture Sensitivity Level (MSL)	1 (Unlimited)	Manufacturer Standard Lead Time	34 Weeks
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Features	Insulation - Class F, Sealed - Flux Protection
Detailed Description	General Purpose Relay SPDT (1 Form C) 24VDC Coil Through Hole	Contact Rating (Current)	16A
Contact Material	Silver Nickel (AgNi)	Contact Form	SPDT (1 Form C)
Coil Voltage	24VDC	Coil Type	Non Latching
Coil Resistance	1.44 kOhms	Coil Power	400 mW
Coil Current	16.7mA
