1422037-2

Agastat Relays / TE Connectivity

Image may be representation. See specifications for product details.

Product Overview

Part Number:	1422037-2
Manufacturer/Brand:	Agastat Relays / TE Connectivity
Product description	RELAY GEN PURPOSE SPDT 3A 12V
Datasheets:	1422037-2.pdf
RoHs Status	Lead free / RoHS Compliant
Stock Condition	24206 pcs stock
Ship From	Hong Kong
Shipment Way	DHL/Fedex/TNT/UPS/EMS

Download Product Details PDF

In Stock 24206 pcs

Reference Price (In US Dollars)

1 pcs: $1.51

10 pcs: $1.414

25 pcs: $1.257

50 pcs: $1.194

100 pcs: $1.131

250 pcs: $1.006

500 pcs: $0.943

1000 pcs: $0.88

Request Quote: Please complete all required fields with your contact information.Click "SUBMIT RFQ" we will contact you shortly by email. Or Email us:[email protected]

Target Price:(USD)
Qty:

Total:$1.51

Please give us your target price if quantities greater than those displayed.

Part Number
Company Name
Contact Name
E-mail
Message

Specifications of 1422037-2

Part Number	1422037-2	Manufacturer	Agastat Relays / TE Connectivity
Description	RELAY GEN PURPOSE SPDT 3A 12V	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	24206 pcs	Data sheet	1422037-2.pdf
Turn On Voltage (Max)	9 VDC	Turn Off Voltage (Min)	1.2 VDC
Termination Style	PC Pin	Switching Voltage	125VAC, 120VDC - Max
Series	V23101, AXICOM	Release Time	5ms
Relay Type	General Purpose	Packaging	Tube
Other Names	1422037-2-ND 14220372 PB1617 V23101D0106A301	Operating Temperature	-40°C ~ 85°C
Operate Time	7ms	Mounting Type	Through Hole
Moisture Sensitivity Level (MSL)	1 (Unlimited)	Manufacturer Standard Lead Time	15 Weeks
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Features	-
Detailed Description	General Purpose Relay SPDT (1 Form C) 12VDC Coil Through Hole	Contact Rating (Current)	3A
Contact Material	Silver Nickel (AgNi)	Contact Form	SPDT (1 Form C)
Coil Voltage	12VDC	Coil Type	Non Latching
Coil Resistance	700 Ohms	Coil Power	206 mW
Coil Current	17.2mA
