Agastat Relays / TE Connectivity
| Part Number | 1375870-7 | Manufacturer | Agastat Relays / TE Connectivity |
|---|---|---|---|
| Description | CON RCPT 18POS | Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Quantity Available | 11071 pcs | Data sheet | 1375870-7.pdf |
| Voltage Rating | 30VAC | Termination | Solder |
| Style | Board to Cable/Wire | Series | AMPMODU Micro |
| Row Spacing - Mating | - | Pitch - Mating | 0.031" (0.80mm) |
| Packaging | Cut Tape (CT) | Other Names | A108839CT |
| Operating Temperature | -55°C ~ 85°C | Number of Rows | 2 |
| Number of Positions Loaded | All | Number of Positions | 18 |
| Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Material Flammability Rating | UL94 V-0 | Mated Stacking Heights | - |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | Insulation Material | Liquid Crystal Polymer (LCP) |
| Insulation Height | 0.197" (5.00mm) | Insulation Color | Natural |
| Ingress Protection | - | Features | Solder Retention |
| Fastening Type | Friction Lock | Detailed Description | 18 Position Receptacle Connector 0.031" (0.80mm) Surface Mount Gold |
| Current Rating | - | Contact Type | Female Blade Socket |
| Contact Shape | - | Contact Material | Phosphor Bronze |
| Contact Length - Post | - | Contact Finish Thickness - Post | 5.11µin (0.130µm) |
| Contact Finish Thickness - Mating | 30.0µin (0.76µm) | Contact Finish - Post | Gold |
| Contact Finish - Mating | Gold | Connector Type | Receptacle |
| Applications | - |
