1-1546074-6

Agastat Relays / TE Connectivity

Image may be representation. See specifications for product details.

Product Overview

Part Number:	1-1546074-6
Manufacturer/Brand:	Agastat Relays / TE Connectivity
Product description	TERM BLK 35 DEGREE 16POS 5.08MM
Datasheets:	1-1546074-6.pdf
RoHs Status	Lead free / RoHS Compliant
Stock Condition	11574 pcs stock
Ship From	Hong Kong
Shipment Way	DHL/Fedex/TNT/UPS/EMS

In Stock 11574 pcs

Reference Price (In US Dollars)

200 pcs: $2.702

Request Quote: Please complete all required fields with your contact information.Click "SUBMIT RFQ" we will contact you shortly by email. Or Email us:[email protected]

Target Price:
Qty:

Total:$2.702

Please give us your target price if quantities greater than those displayed.

Part Number
Company Name
Contact Name
E-mail
Message

Specifications of 1-1546074-6

Part Number	1-1546074-6	Manufacturer	Agastat Relays / TE Connectivity
Description	TERM BLK 35 DEGREE 16POS 5.08MM	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	11574 pcs	Data sheet	1-1546074-6.pdf
Wire Termination	Screw - Rising Cage Clamp	Wire Gauge	12-30 AWG
Voltage	300V	Torque - Screw	0.79 Nm (7.0 Lb-In)
Series	Buchanan	Screw Thread	M3
Screw Material - Plating	Brass - Nickel Plated	Positions Per Level	16
Pitch	0.200" (5.08mm)	Packaging	Bulk
Operating Temperature	-40°C ~ 105°C	Number of Levels	1
Mounting Type	Through Hole	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Mating Orientation	35° (145°) Angle with Board	Manufacturer Standard Lead Time	21 Weeks
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Housing Material	Polyamide (PA66), Nylon 6/6
Features	Interlocking (Side)	Detailed Description	16 Position Wire to Board Terminal Block 35° (145°) Angle with Board 0.200" (5.08mm) Through Hole
Current	17.5A	Contact Material - Plating	Brass - Tin Plated
Color	Black	Clamp Material - Plating	Brass - Nickel Plated
