0022292131 Image
Image may be representation. See specifications for product details.

Product Overview

Part Number: 0022292131
Manufacturer/Brand: Affinity Medical Technologies - a Molex company
Product description 2.54MM KK HDR VT FRICLK 13POS
Datasheets: 0022292131.pdf
RoHs Status Lead free / RoHS Compliant
Stock Condition 102711 pcs stock
Ship From Hong Kong
Shipment Way DHL/Fedex/TNT/UPS/EMS
In Stock 102711 pcs
Reference Price (In US Dollars)
4000 pcs
$0.374
Request Quote
Please complete all required fields with your contact information.Click "SUBMIT RFQ" we will contact you shortly by email. Or Email us:[email protected]
  • Target Price:
  • Qty:
Total:$0.374

Please give us your target price if quantities greater than those displayed.

  • Part Number
  • Company Name
  • Contact Name
  • E-mail
  • Message

Specifications of 0022292131

Part Number 0022292131 Manufacturer Affinity Medical Technologies - a Molex company
Description 2.54MM KK HDR VT FRICLK 13POS Lead Free Status / RoHS Status Lead free / RoHS Compliant
Quantity Available 102711 pcs Data sheet 0022292131.pdf
Voltage Rating - Termination Solder
Style Board to Cable/Wire Shrouding Shrouded - 1 Wall
Series KK 6410 Row Spacing - Mating -
Pitch - Mating 0.100" (2.54mm) Packaging Bulk
Overall Contact Length 0.560" (14.22mm) Other Names 0022-29-2131
002229-2131
22-29-2131
22292131
AE-6410-13A(241)
Operating Temperature - Number of Rows 1
Number of Positions Loaded All Number of Positions 13
Mounting Type Through Hole Moisture Sensitivity Level (MSL) 1 (Unlimited)
Material Flammability Rating UL94 V-0 Mated Stacking Heights -
Manufacturer Standard Lead Time 9 Weeks Lead Free Status / RoHS Status Lead free / RoHS Compliant
Insulation Material Polyamide (PA), Nylon Insulation Height 0.461" (11.70mm)
Insulation Color Natural Ingress Protection -
Features - Fastening Type Friction Lock
Detailed Description Connector Header Through Hole 13 position 0.100" (2.54mm) Current Rating -
Contact Type Male Pin Contact Shape Square
Contact Material Brass Contact Length - Post 0.140" (3.56mm)
Contact Length - Mating 0.295" (7.49mm) Contact Finish Thickness - Post 100.0µin (2.54µm)
Contact Finish Thickness - Mating 20.0µin (0.51µm) Contact Finish - Post Tin
Contact Finish - Mating Gold Connector Type Header
Applications Automotive, General Purpose, Medical, Telecommunications
