0022284223

Affinity Medical Technologies - a Molex company

Image may be representation. See specifications for product details.

Product Overview

Part Number:	0022284223
Manufacturer/Brand:	Affinity Medical Technologies - a Molex company
Product description	CONN HEADER 22POS .100 VERT GOLD
Datasheets:	1.0022284223.pdf 2.0022284223.pdf
RoHs Status	Lead free / RoHS Compliant
Stock Condition	77322 pcs stock
Ship From	Hong Kong
Shipment Way	DHL/Fedex/TNT/UPS/EMS

In Stock 77322 pcs

Reference Price (In US Dollars)

1 pcs: $0.495

10 pcs: $0.45

25 pcs: $0.423

50 pcs: $0.404

100 pcs: $0.386

250 pcs: $0.349

500 pcs: $0.321

Request Quote: Please complete all required fields with your contact information.Click "SUBMIT RFQ" we will contact you shortly by email. Or Email us:[email protected]

Target Price:
Qty:

Total:$0.495

Please give us your target price if quantities greater than those displayed.

Part Number
Company Name
Contact Name
E-mail
Message

Specifications of 0022284223

Part Number	0022284223	Manufacturer	Affinity Medical Technologies - a Molex company
Description	CONN HEADER 22POS .100 VERT GOLD	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	77322 pcs	Data sheet	1.0022284223.pdf 2.0022284223.pdf
Voltage Rating	-	Termination	Solder
Style	Board to Board or Cable	Shrouding	Unshrouded
Series	KK 42375	Row Spacing - Mating	-
Pitch - Mating	0.100" (2.54mm)	Packaging	Bulk
Overall Contact Length	0.455" (11.56mm)	Other Names	0022-28-4223 0022-28-4223-E 0022284223-E 22-28-4223 22-28-4223-E 22-28-4223-ND 22284223 22284223-E WM50016-22 WM6522 WM6522-ND
Operating Temperature	-	Number of Rows	1
Number of Positions Loaded	All	Number of Positions	22
Mounting Type	Through Hole	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Material Flammability Rating	UL94 V-0	Mated Stacking Heights	-
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Insulation Material	Polyamide (PA), Nylon, Glass Filled
Insulation Height	0.090" (2.29mm)	Insulation Color	Black
Ingress Protection	-	Features	-
Fastening Type	Push-Pull	Detailed Description	Connector Header Through Hole 22 position 0.100" (2.54mm)
Current Rating	-	Contact Type	Male Pin
Contact Shape	Square	Contact Material	-
Contact Length - Post	0.125" (3.18mm)	Contact Length - Mating	0.240" (6.10mm)
Contact Finish Thickness - Post	100.0µin (2.54µm)	Contact Finish Thickness - Mating	15.0µin (0.38µm)
Contact Finish - Post	Tin	Contact Finish - Mating	Gold
Connector Type	Header, Breakaway	Applications	Automotive, General Purpose, Medical, Telecommunications
