0022280365

Affinity Medical Technologies - a Molex company

Image may be representation. See specifications for product details.

Product Overview

Part Number:	0022280365
Manufacturer/Brand:	Affinity Medical Technologies - a Molex company
Product description	KK 100 HDR VERT 36 CKT GOLD
Datasheets:	1.0022280365.pdf 2.0022280365.pdf
RoHs Status	Lead free / RoHS Compliant
Stock Condition	6129 pcs stock
Ship From	Hong Kong
Shipment Way	DHL/Fedex/TNT/UPS/EMS

In Stock 6129 pcs

Request Quote: Please complete all required fields with your contact information.Click "SUBMIT RFQ" we will contact you shortly by email. Or Email us:[email protected]

Target Price:(USD)
Qty:

Please give us your target price if quantities greater than those displayed.

Part Number
Company Name
Contact Name
E-mail
Message

Specifications of 0022280365

Part Number	0022280365	Manufacturer	Affinity Medical Technologies - a Molex company
Description	KK 100 HDR VERT 36 CKT GOLD	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	6129 pcs	Data sheet	1.0022280365.pdf 2.0022280365.pdf
Voltage Rating	-	Termination	Kinked Pin, Solder
Style	Board to Board or Cable	Shrouding	Shrouded - 1 Wall
Series	KK 42227	Row Spacing - Mating	-
Pitch - Mating	0.100" (2.54mm)	Packaging	Bulk
Overall Contact Length	0.555" (14.10mm)	Other Names	002228-0365 22-28-0365 2228-0365 22280365 42227-0211
Operating Temperature	-	Number of Rows	1
Number of Positions Loaded	All	Number of Positions	36
Mounting Type	Through Hole	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Material Flammability Rating	UL94 V-0	Mated Stacking Heights	-
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Insulation Material	Polyamide (PA), Nylon, Glass Filled
Insulation Height	0.337" (8.56mm)	Insulation Color	Black
Ingress Protection	-	Features	-
Fastening Type	Friction Lock	Detailed Description	Connector Header Through Hole 36 position 0.100" (2.54mm)
Current Rating	-	Contact Type	Male Pin
Contact Shape	Square	Contact Material	-
Contact Length - Post	0.135" (3.43mm)	Contact Length - Mating	0.295" (7.49mm)
Contact Finish Thickness - Post	100.0µin (2.54µm)	Contact Finish Thickness - Mating	30.0µin (0.76µm)
Contact Finish - Post	Tin	Contact Finish - Mating	Gold
Connector Type	Header, Breakaway	Applications	Automotive, General Purpose, Medical, Telecommunications
