AVX Corporation
| Part Number | 046288032000846+ | Manufacturer | AVX Corporation |
|---|---|---|---|
| Description | CONN FFC BOTTOM 32POS 0.50MM R/A | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 2765 pcs | Data sheet | 046288032000846+.pdf |
| Voltage Rating | 50V | Termination | Solder |
| Series | 6288, Kyocera | Pitch | 0.020" (0.50mm) |
| Packaging | Cut Tape (CT) | Other Names | 46288032000846 478-5463-1 |
| Operating Temperature | -40°C ~ 105°C | Number of Positions | 32 |
| Mounting Type | Surface Mount, Right Angle | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Mating Cycles | - | Material Flammability Rating | - |
| Locking Feature | Flip Lock | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Housing Material | Plastic | Housing Color | - |
| Height Above Board | 0.079" (2.00mm) | Flat Flex Type | FFC, FPC |
| Features | Solder Retention, Zero Insertion Force (ZIF) | FFC, FCB Thickness | 0.30mm |
| Detailed Description | 32 Position FFC, FPC Connector Contacts, Bottom 0.020" (0.50mm) Surface Mount, Right Angle | Current Rating | 0.4A |
| Contact Material | Copper Alloy | Contact Finish Thickness | 3.90µin (0.099µm) |
| Contact Finish | Gold | Connector/Contact Type | Contacts, Bottom |
| Cable End Type | Tabbed | Actuator Material | - |
| Actuator Color | - |
