AMI Semiconductor / ON Semiconductor
| Part Number | NSBC143ZPDP6T5G | Manufacturer | AMI Semiconductor / ON Semiconductor |
|---|---|---|---|
| Description | TRANS 2NPN PREBIAS 0.339W SOT963 | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 830348 pcs | Data sheet | NSBC143ZPDP6T5G.pdf |
| Voltage - Collector Emitter Breakdown (Max) | 50V | Vce Saturation (Max) @ Ib, Ic | 250mV @ 1mA, 10mA |
| Transistor Type | 2 NPN - Pre-Biased (Dual) | Supplier Device Package | SOT-963 |
| Series | - | Resistor - Emitter Base (R2) | 47 kOhms |
| Resistor - Base (R1) | 4.7 kOhms | Power - Max | 339mW |
| Packaging | Tape & Reel (TR) | Package / Case | SOT-963 |
| Other Names | NSBC143ZPDP6T5G-ND NSBC143ZPDP6T5GOSTR |
Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 12 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Frequency - Transition | - |
| Detailed Description | Pre-Biased Bipolar Transistor (BJT) 2 NPN - Pre-Biased (Dual) 50V 100mA 339mW Surface Mount SOT-963 | DC Current Gain (hFE) (Min) @ Ic, Vce | 80 @ 5mA, 10V |
| Current - Collector Cutoff (Max) | 500nA | Current - Collector (Ic) (Max) | 100mA |
| Base Part Number | NSBC1* |
