Molex, LLC
| Part Number | 0022282087 | Manufacturer | Molex, LLC |
|---|---|---|---|
| Description | KK 100 HDR POL BWR RTAN 8POS TIN | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 248366 pcs | Data sheet | 1.0022282087.pdf2.0022282087.pdf |
| Voltage - DC Spark Over (Nom) | - | Type Attributes | - |
| Termination | Solder | Style | Board to Board or Cable |
| Stacking Direction | Male Pin | Shrouding | 0.100" (2.54mm) |
| Shield Termination | Square | Series | KK® 42226 |
| Row Spacing - Mating | Shrouded - 1 Wall | RoHS Status | Bulk |
| Ripple Current - Low Frequency | Automotive, General Purpose, Medical, Telecommunications | Pitch - Connector | - |
| Overall Contact Length | 0.120" (3.05mm) | Other Names | 0022-28-2087 002228-2087 22-28-2087 22282087 42226-0218 |
| Operating Temperature | - | Number of Rows | 1 |
| Number of Positions | 8 | Number of Contacts | 100µin (2.54µm) |
| Mounting Type | Through Hole, Right Angle | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Material Flammability Rating | UL94 V-0 | Material - Insulation | All |
| Manufacturer Standard Lead Time | 10 Weeks | Manufacturer Part Number | 0022282087 |
| Length - Post (Mating) | - | Insulation Material | Tin |
| Insulation Height | - | Features | - |
| Expanded Description | 8 Positions Header, Breakaway Connector 0.100" (2.54mm) Through Hole, Right Angle Tin | Description | KK 100 HDR POL BWR RTAN 8POS TIN |
| Current Rating | - | Current - Max/Contact | - |
| Contact Length - Post | 0.295" (7.49mm) | Contact Length - Mating | - |
| Contact Finish Thickness - Post | Polyamide (PA), Nylon, Glass Filled | Contact Finish Thickness - Mating | Tin |
| Contact Finish - Post | 100µin (2.54µm) | Contact Finish - Mating | 0.284" (7.20mm) |
| Connector Type | Header, Breakaway | Actual Diameter | Black |
