929815-01-19-I

Image may be representation. See specifications for product details.

Product Overview

Part Number:	929815-01-19-I
Manufacturer/Brand:	3M
Product description	CONN HEADER 38POS DL .100" GOLD
Datasheets:	929815-01-19-I.pdf
RoHs Status	Lead free / RoHS Compliant
Stock Condition	14414 pcs stock
Ship From	Hong Kong
Shipment Way	DHL/Fedex/TNT/UPS/EMS

In Stock 14414 pcs

Reference Price (In US Dollars)

300 pcs: $2.134

Request Quote: Please complete all required fields with your contact information.Click "SUBMIT RFQ" we will contact you shortly by email. Or Email us:[email protected]

Target Price:
Qty:

Total:$2.134

Please give us your target price if quantities greater than those displayed.

Part Number
Company Name
Contact Name
E-mail
Message

Specifications of 929815-01-19-I

Part Number	929815-01-19-I	Manufacturer	3M
Description	CONN HEADER 38POS DL .100" GOLD	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	14414 pcs	Data sheet	929815-01-19-I.pdf
Voltage Rating	-	Termination	Solder
Style	Board to Board	Shrouding	Unshrouded
Series	929	Row Spacing - Mating	0.100" (2.54mm)
Pitch - Mating	0.100" (2.54mm)	Packaging	Bulk
Overall Contact Length	0.303" (7.70mm)	Other Names	00076308063092 07630806309 7630806309 76308063092 80001342387
Operating Temperature	-40°C ~ 105°C	Number of Rows	2
Number of Positions Loaded	All	Number of Positions	38
Mounting Type	Through Hole	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Material Flammability Rating	UL94 V-0	Mated Stacking Heights	-
Manufacturer Standard Lead Time	3 Weeks	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Insulation Material	Polybutylene Terephthalate (PBT), Polyester, Glass Filled	Insulation Height	0.115" (2.92mm)
Insulation Color	Black	Ingress Protection	-
Features	-	Fastening Type	Push-Pull
Detailed Description	Connector Header Through Hole 38 position 0.100" (2.54mm)	Current Rating	2.5A
Contact Type	Male Pin	Contact Shape	Square
Contact Material	Copper Alloy	Contact Length - Post	0.110" (2.79mm)
Contact Length - Mating	0.093" (2.36mm)	Contact Finish Thickness - Post	10.0µin (0.25µm)
Contact Finish Thickness - Mating	10.0µin (0.25µm)	Contact Finish - Post	Gold
Contact Finish - Mating	Gold	Connector Type	Header
Applications	-
