3M
| Part Number | 929648-05-12-EU | Manufacturer | 3M |
|---|---|---|---|
| Description | CONN HEADER 12POS R/A .100" GOLD | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 50754 pcs | Data sheet | |
| Voltage - DC Spark Over (Nom) | Copper Alloy | Type Attributes | - |
| Termination | Solder | Style | Board to Board |
| Stacking Direction | Male Pin | Shrouding | 0.100" (2.54mm) |
| Shield Termination | Square | Series | 929 |
| Row Spacing - Mating | Unshrouded | RoHS Status | Bulk |
| Ripple Current - Low Frequency | - | Pitch - Connector | - |
| Overall Contact Length | 0.520" (13.21mm) | Other Names | 00076308042905 07630804290 7630804290 76308042905 80001322199 |
| Operating Temperature | -40°C ~ 105°C | Number of Rows | 1 |
| Number of Positions | 12 | Number of Contacts | 10µin (0.25µm) |
| Mounting Type | Through Hole, Right Angle | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Material Flammability Rating | UL94 V-0 | Material - Insulation | All |
| Manufacturer Standard Lead Time | 3 Weeks | Manufacturer Part Number | 929648-05-12-EU |
| Length - Post (Mating) | - | Insulation Material | Gold |
| Insulation Height | - | Features | - |
| Expanded Description | 12 Positions Header, Breakaway Connector 0.100" (2.54mm) Through Hole, Right Angle Gold | Description | CONN HEADER 12POS R/A .100" GOLD |
| Current Rating | 2.5A | Current - Max/Contact | - |
| Contact Length - Post | 0.235" (5.97mm) | Contact Length - Mating | - |
| Contact Finish Thickness - Post | Polycyclohexylenedimethylene Terephthalate (PCT) | Contact Finish Thickness - Mating | Gold |
| Contact Finish - Post | 10µin (0.25µm) | Contact Finish - Mating | 0.115" (2.92mm) |
| Connector Type | Header, Breakaway | Actual Diameter | Black |
