NKK Switches
| Part Number | SS314MAH4-R | Manufacturer | NKK Switches |
|---|---|---|---|
| Description | SWITCH SLIDE SPDT 0.4VA 28V | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 29820 pcs | Data sheet | SS314MAH4-R.pdf |
| Voltage Rating - DC | 28V | Voltage Rating - AC | 28V |
| Termination Style | Gull Wing | Switch Travel | 2.00mm |
| Switch Function | On-Off-On | Series | SS3 |
| Packaging | Cut Tape (CT) | Other Names | 360-4051-1 |
| Operating Temperature | -25°C ~ 85°C | Operating Force | - |
| Mounting Type | Surface Mount, Right Angle | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Mechanical Life | 10,000 Cycles | Manufacturer Standard Lead Time | 5 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Features | - |
| Electrical Life | 10,000 Cycles | Detailed Description | Slide Switch SPDT Surface Mount, Right Angle |
| Current Rating | 0.4VA (AC/DC) | Contact Timing | Non-Shorting (BBM) |
| Contact Material | Phosphor Bronze | Contact Finish | Gold |
| Circuit | SPDT | California Prop 65 | Warning Information WARNING: This product can expose you to chemicals including Antimony oxide (Antimony trioxide) and Nickel (Metallic) which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65warnings.ca.gov. |
| Actuator Type | Standard | Actuator Material | Polyphenylene Sulfide (PPS) |
| Actuator Length | 2.00mm |
