Siglent 2Gsample/s scope offers 350MHz bandwidth

Available with a choice of 200 or 350MHz bandwidth, the SDS2000X-E – where the trailing E stands for economy models, said the firm.

28Mpoint of acquisition memory is available as standard, as is an update rate of up 110,000waveform/s.

“Low noise front end and vertical sensitivity of 500µV/div combine to provide a troubleshooting tool that technicians and engineers can rely on when analysing small signals and hard-to-find issues,” accrding to Siglent.

FFT up to 1M sample is available for frequency domain EMI troubleshooting and spectral analysis, and there is serial bus triggering and decoding for I2C, SPI, UART, CAN, LIN busses.

Bode plotting is also included. “When combined with a Siglent signal generator, the X-E coordinates frequency response characterisation for filters or determining stability though phase and gain margin measurements in closed loop circuits,” said the firm.

Options include:

• 16 digital input channels (SDS2000X-E-16LA/SLA1016)
• external single channel signal generator (SDS2000X-E-FG/SAG1021)
• WiFi (SDS2000X-E-WiFi/TL-WN725N)

Prices start at €539 plus VAT.
